Results
You searched for: BACK TURNING INSERTS
Results Displayed: 1 - 9 of 9
Item IDDescriptionUOMQuantity
G6BRA30BLU
130400020
#Edges:6;#Teeth:1;Coated;Dep of Cut:0.15"/3.8mm;EX-RH;Feed (in/rev):0.0020-0.0050;Feed (mm/rev):0.0500-0.1200;Insert Type:G6;Lead Ang:12°;Lead Ang:30°;Matl:Carbide;Nose Flat Ang:0.02;Rad:0.004"/0.1mm;Rel Ang:30°;Rel Clear:3.8mm
GB19RA30BLU
130100001
#Edges:3;Chamf Ht-Max:4.3mm;Chamf Wid:3.4mm;Dep of Cut:5.4mm;EX-RH;Feed (mm/rev):0.0500-0.1500;Grade:BLU;Insert Size:19mm;Lead Ang:12°;Matl:Carbide;Nose Flat Wid:0.5mm;Rad:0.1mm;Rel Ang:30°
GB20RA30BLU
130200003
#Edges:3;Chamf Ht-Max:4.3mm;Chamf Wid:3.4mm;Dep of Cut:6.4mm;EX-RH;Feed (mm/rev):0.0500-0.1500;Grade:BLU;Insert Size:20mm;Lead Ang:12°;Matl:Carbide;Nose Flat Wid:0.5mm;Rad:0.1mm;Rel Ang:30°
GB25LA30R03BLU
130300044
#Edges:2;#Teeth:1;Dep of Cut:0.157";EX-LH;Feed (in/rev):0.0020-0.0050;Grade:BLU;Insert Size:25mm;Lead Ang:15°;Lead Ang:30°;Matl:Carbide;Nose Flat Wid:0.118";Rad:0.001";Rel Clear:0.315"
GB25LA30R10BLU
130300045
#Edges:2;#Teeth:1;Dep of Cut:0.157";EX-LH;Feed (in/rev):0.0020-0.0050;Grade:BLU;Insert Size:25mm;Lead Ang:15°;Lead Ang:30°;Matl:Carbide;Nose Flat Wid:0.118";Rad:0.004";Rel Clear:0.315"
GB25LA30R20BLU
130300247
#Edges:2;#Teeth:1;Dep of Cut:0.157";EX-LH;Feed (in/rev):0.0020-0.0050;Grade:BLU;Insert Size:25mm;Lead Ang:15°;Lead Ang:30°;Matl:Carbide;Nose Flat Wid:0.118";Rad:0.008";Rel Clear:0.315"
GB25RA30R03BLU
130300008
#Edges:2;#Teeth:1;Dep of Cut:0.157"/4.0mm;EX-RH;Feed (in/rev):0.0020-0.0050;Feed (mm/rev):0.0500-0.1200;Grade:BLU;Insert Size:25mm;Lead Ang:15°;Lead Ang:30°;Matl:Carbide;Nose Flat Wid:0.118"/3mm;Rad:0.001"/0.03mm;Rel Ang:30°;Rel Clear:0.315"/8.0mm
GB25RA30R10BLU
130300028
#Edges:2;#Teeth:1;Dep of Cut:0.157"/4.0mm;EX-RH;Feed (in/rev):0.0020-0.0050;Feed (mm/rev):0.0500-0.1200;Grade:BLU;Insert Size:25mm;Lead Ang:15°;Lead Ang:30°;Matl:Carbide;Nose Flat Wid:0.118"/3mm;Rad:0.004"/0.1mm;Rel Ang:30°;Rel Clear:0.315"/8.0mm
GB25RA30R20BLU
130300185
#Edges:2;#Teeth:1;Dep of Cut:0.157"/4.0mm;EX-RH;Feed (in/rev):0.0020-0.0050;Feed (mm/rev):0.0500-0.1200;Grade:BLU;Insert Size:25mm;Lead Ang:15°;Lead Ang:30°;Matl:Carbide;Nose Flat Wid:0.118"/3mm;Rad:0.008"/0.2mm;Rel Ang:30°;Rel Clear:0.315"/8.0mm
